Modifying a GM Dynaride Suspension (auto-leveller) Compressor To Work With Air-Lift Bags

llcomp01

llcomp02

llcomp03

llcomp04

The Compressor

Opening Dryer

Spring Removal

Cap Assembly

llcomp05

llcomp06
llcomp07

Interior

Spring Comparo
Spring Cut

I got the inspiration for this mod (and several others) from Gerry Charlesworth (95Wagon).

Installing the air bags into the rear springs is straight forward and covered well by many other posts on the ImpalaSS Forum.

I connected the bags to the existing air line by cutting one of the "male" special connectors out of an old O.E.M.airshock, and then used JB-Weld to bond it with the "Tee" fitting provided with the air bags. This allowed me to connect to the original supply line in the vehicle, and then run the Air-Lift hoses from the "Tee" to the separate bags. I don't intend to do any serious racing with my wagon so the shared supply suits me just fine. I will get a picture of this fitting and add it to the site at another time.
